Get even more out of your tractor
Tractor Back Blades
You can also check out our catalog if you are interested in learning more about our Back Blades!
2023-2024 season Starts May 1 Discounts Available Until July 31
Ebling Back Blade Products
Truck and Tractors:
16ft Hydraulic Wing Truck Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 3/4 ton and 1 ton single rear wheel trucks.
- 90" Moldboard.
- 21" blade height
- Approximately 4ft wings
- Overall width in the open position: 16'
- Overall width in the closed position: 8'
- Approximate blade weight: 825 lbs.
- 4 arm lift system ensures a straight vertical lift pattern.
- Adjustable top arms to accommodate different height trucks.
- Adjustable QD arms making the blade universal to fit other trucks.
- Bucher hydraulic pump is hard wired to the vehicles electrical system.
- Hydraulic pump is mounted to the plow and is protected by a 3/16 steel pump box with an easy to remove steel top.
- Hydraulic down pressure for maximum scraping action. Relief set at 2300 lbs.
- 1/2" Carbon steel moldboard cutting edge and durable 1 1/2" x 6" Type 2 Polyurethane wing cutting edges are standard.
- Horizontal Spring bar keeps the back blade level while in the up position.
- Break away shear bolt on each wing along with hydraulic relief reduces the possibility for cylinder and wing damage when an obstruction is hit.
- Remote switch at rear of truck mounted on a stainless steel plate or recessed in the bed of truck for quick attach/detach of back blade.
- Professional control box can be mounted in cab and unplugged during off season.
- Full use of truck tailgate
- Built in plow stand for off season storage.
- Ebling Truck Mount replaces OEM receiver hitch for all Ford and 19-prior GM trucks. Ebling truck mount is installed on 20-newer GM & Dodge trucks without disrupting the 2" receiver hitch.
- Ebling Truck Mount is specific to vehicle make/model/year/box length
- Consult Ebling when mounting to trucks with dual wheels or trucks that have a flat/dump bed.
- Powder coat finish.
- 1 year warranty
14ft Hydraulic Wing Truck Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 3/4 ton and 1 ton single rear wheel trucks.
- 90" Moldboard.
- 21" blade height
- Approximately 3ft wings
- Overall width in the open position: 14'
- Overall width in the closed position: 8'
- Approximate blade weight: 775 lbs.
- 4 arm lift system ensures a straight vertical lift pattern.
- Adjustable top arms to accommodate different height trucks.
- Adjustable QD arms making the blade universal to fit other trucks.
- Bucher hydraulic pump is hard wired to the vehicles electrical system.
- Hydraulic pump is mounted to the plow and is protected by a 3/16 steel pump box with an easy to remove steel top.
- Hydraulic down pressure for maximum scraping action. Relief set at 2300 lbs.
- 1/2" Carbon steel moldboard cutting edge and durable 1 1/2" x 6" Type 2 Polyurethane wing cutting edges are standard.
- Break away shear bolt on each wing along with hydraulic relief reduces the possibility for cylinder and wing damage when an obstruction is hit.
- Remote switch at rear of truck mounted on a stainless steel plate or recessed in truck bed for quick attach/detach of back blade
- Professional control box can be mounted in cab and unplugged during off season.
- Full use of truck tailgate
- Built in plow stand for off season storage.
- Ebling Truck Mount replaces OEM receiver hitch for all Ford and 19-prior GM trucks. Ebling truck mount is installed on 20-newer GM & Dodge trucks without disrupting the 2" receiver hitch.
- Ebling Truck Mount is specific to vehicle make/model/year/box length.
- Consult Ebling when mounting to trucks with dual wheels or trucks that have a flat/dump bed.
- Powder coat finish.
- 1 year warranty
12ft Hydraulic Wing Truck Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 3/4 ton and 1 ton single rear wheel trucks.
- 90" Moldboard.
- 21" blade height
- Approximately 2ft wings
- Overall width in the open position: 12'
- Overall width in the closed position: 8'
- Approximate blade weight: 715 lbs.
- 4 arm lift system ensures a straight vertical lift pattern.
- Adjustable top arms to accommodate different height trucks.
- Adjustable QD arms making the blade universal to fit other trucks.
- Bucher hydraulic pump is hard wired to the vehicles electrical system.
- Hydraulic pump is mounted to the plow and is protected by a 3/16 steel pump box with an easy to remove steel top.
- Hydraulic down pressure for maximum scraping action. Relief set at 2300 lbs.
- 1/2" Carbon steel moldboard cutting edge and durable 1 1/2" x 6" Type 2 Polyurethane wing cutting edges are standard.
- Break away shear bolt on each wing along with hydraulic relief reduces the possibility for cylinder and wing damage when an obstruction is hit.
- Remote switch at rear of truck mounted on a stainless steel plate or recessed in truck bed for quick attach/detach of back blade.
- Professional control box can be mounted in cab and unplugged during off season.
- Full use of truck tailgate
- Built in plow stand for off season storage.
- Ebling Truck Mount replaces OEM receiver hitch for all Ford and 19-prior GM trucks. Ebling truck mount is installed on 20-newer GM & Dodge trucks without disrupting the 2" receiver hitch.
- Ebling Truck Mount is specific to vehicle make/model/year/box length
- Consult Ebling when mounting to trucks with dual wheels or trucks that have a flat/dump bed.
- Powder coat finish.
- 1 year warranty
8ft. Fixed wing Truck Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 3/4 ton and 1 ton single rear wheel trucks.
- 96" Moldboard.
- 21" blade height
- 2ft wings bolted to the side of the moldboard
- Support arm on inside of each wing creates a strong rigid plow corner.
- Approximate blade weight: 610 lbs.
- 4 arm lift system ensures a straight vertical lift pattern.
- Adjustable top arms to accommodate different height trucks.
- Adjustable QD arms making the blade universal to fit other trucks.
- Bucher hydraulic pump is hard wired to the vehicles electrical system.
- Hydraulic pump is mounted to the plow and is protected by a 3/16 steel pump box with an easy to remove steel top.
- Hydraulic down pressure for maximum scraping action. Relief set at 2300 lbs.
- 1/2" Carbon steel moldboard cutting edge and durable 1 1/2" x 6" Type 2 Polyurethane wing cutting edges are standard.
- Remote switch at rear of truck mounted on a stainless steel plate or recessed in truck bed for quick attach/detach of back blade.
- Professional control box can be mounted in cab and unplugged during off season.
- Full use of truck tailgate
- Built in plow stand for off season storage.
- Ebling Truck Mount replaces OEM receiver hitch for all Ford and 19-prior GM trucks. Ebling truck mount is installed on 20-newer GM & Dodge trucks without disrupting the 2" receiver hitch.
- Ebling Truck Mount is specific to vehicle make/model/year/box length
- Consult Ebling when mounting to trucks with dual wheels or trucks that have a flat/dump bed.
- Powder coat finish.
- 1 year warranty.
Sidekick 7, 7.5 or 8′ For
1/2 Ton Trucks & UTVs
TAKING ORDERS MAY 1
- Designed for 1/2-1 ton pickup trucks, SUV''s, Jeeps and most 4wd vehicles with a 2" receiver style trailer hitch.
- The SIDEKICK attachment system slides into a vehicles existing 2" receiver hitch and is supported by 2 additional ratchet style straps.
- 2 arm lift system is adjustable to fit different vehicle heights.
- 7 gauge Universal moldboard is adjustable from 7ft-7.5ft-8ft to accommodate different vehicle widths. Simply slide in or out to desired width and bolt in place.
- Self contained Bucher hydraulic pump is hard wired to the vehicles electrical system and is protected from the elements by a steel pump box with removable top.
- Hydraulic down pressure for excellent scraping action.
- Professional control box can be mounted in cab and unplugged during off season.
- Carbon steel cutting edge on the main moldboard and 1 1/2"x 6" Polyurethane cutting edges on the wings is standard.
- Plow stand for off season storage.
- Approximately 382 lbs.
- Powder-coat finish.
- 1 year Warranty
16ft Category 2 Tractor Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 4wd tractors with a minimum of 50hp and a Category I or 2 three point hitch.
- One piece all welded construction on moldboard and wings.
- Moldboard also accepts a 3ft wing to make the blade 16ft overall.
- Moldboard cutting edge is raked forward for improved scraping action.
- 3/4" x 6" Carbon steel cutting edge on main moldboard and 1 1/2"x 6" Polyurethane cutting edge on wing is standard.
- Break away shear bolt on each wing reduces the possibility for cylinder and wing damage when an obstruction is hit.
- Controls utilize the on-board 3 point and auxiliary hydraulics of the tractor.
- 2 sets of hydraulic remotes are required on the tractor for independent wing control.
- Wings rotate 90 degrees total and may be started or stopped in any position.
- Blade height: 30"
- Moldboard size: 102"
- Approximate wing size: 32"
- Blade width closed: 110"
- Blade width fully open: 192"
- Approximate blade weight: 1058 lbs
- Powder Coat finish
- 1 year warranty
16ft Category 1 Tractor Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 4wd tractors with a minimum of 50hp and a Category I or 2 three point hitch.
- One piece all welded construction on moldboard and wings.
- Moldboard also accepts a 4ft wing to make the blade 16ft overall.
- Moldboard cutting edge is raked forward for improved scraping action.
- 3/4" x 6" Carbon steel cutting edge on main moldboard and 1 1/2"x 6" Polyurethane cutting edge on wing is standard.
- Break away shear bolt on each wing reduces the possibility for cylinder and wing damage when an obstruction is hit.
- Controls utilize the on-board 3 point and auxiliary hydraulics of the tractor.
- 2 sets of hydraulic remotes are required on the tractor for independent wing control.
- Wings rotate 90 degrees total and may be started or stopped in any position.
- Blade height: 24"
- Moldboard size: 96"
- Approximate wing size: 48"
- Blade width closed: 104"
- Blade width fully open: 192"
- Approximate blade weight: 875 lbs
- Powder Coat finish
- 1 year warranty
14ft Category 1 Tractor Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 4wd tractors with a minimum of 45hp and a Category I three point hitch.
- One piece all welded construction on moldboard and wings.
- Moldboard also accepts a 4ft wing to make the blade 14ft overall.
- Moldboard cutting edge is raked forward for improved scraping action.
- 1/2" x 6" Carbon steel cutting edge on main moldboard and 1 1/2"x 6" Polyurethane cutting edge on wings is standard.
- Break away shear bolt on each wing reduces the possibility for cylinder and wing damage when an obstruction is hit.
- Controls utilize the on-board 3 point and auxiliary hydraulics of the tractor.
- 2 sets of hydraulic remotes are required on the tractor for independent wing control.
- Wings rotate 90 degrees total and may be started or stopped in any position.
- Blade height: 24"
- Moldboard size: 72"
- Approximate wing size: 48"
- Blade width closed: 80"
- Blade width fully open: 168"
- Approximate blade weight: 717 lbs
- Powder Coat finish
- 1 year warranty
12ft Category 1 Tractor Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 4wd tractors with a minimum of 40hp and a Category I three point hitch.
- One piece all welded construction on moldboard and wings.
- Moldboard also accepts a 2ft wing to make the blade 12ft overall.
- Moldboard cutting edge is raked forward for improved scraping action.
- 3/4" x 6" Carbon steel cutting edge on main moldboard and 1 1/2"x 6" Polyurethane cutting edge on wings is standard.
- Break away shear bolt on each wing reduces the possibility for cylinder and wing damage when an obstruction is hit.
- Controls utilize the on-board 3 point hitch and the auxiliary hydraulics of the tractor.
- 2 sets of hydraulic remotes are required on the tractor for independent wing control.
- Wings rotate 90 degrees total and may be started or stopped in any position.
- Blade height: 24"
- Moldboard size: 96"
- Approximate wing size: 24"
- Blade width closed: 104"
- Blade width fully open: 144"
- Approximate blade weight: 725 lbs
- Powder Coat finish
- 1 year warranty
10ft Category 1 Tractor Backblade
TAKING ORDERS MAY 1
- Heavy duty back blade designed for 4wd tractors with a minimum of 35hp and a Category I three point hitch.
- One piece all welded construction of moldboard and wings.
- Moldboard also accepts a 2ft wing to make the blade 10ft overall.
- Moldboard cutting edge is raked forward for improved scraping action.
- 1/2" x 6" Carbon steel cutting edge on main moldboard and 1 1/2"x 6" Polyurethane cutting edge on wings is standard.
- Break away shear bolt on each wing reduces the possibility for cylinder and wing damage when an obstruction is hit.
- Controls utilize the on-board 3 point hitch and auxiliary hydraulics of the tractor.
- 2 sets of hydraulic remotes are required on the tractor for independent wing control.
- Wings rotate 90 degrees total and may be started or stopped in any position.
- Blade height: 24"
- Moldboard size: 72"
- Approximate wing size: 24"
- Blade width closed: 80"
- Blade width fully open: 120"
- Approximate blade weight: 597 lbs
- Powder Coat finish
- 1 year warranty
Check out the Truck Back Blades
Ebling Back Blade in Action:
You can also check out our catalog if you are interested in learning more about our Back Blades!
cUSTOM COLORS AVAILABLE
